AD 2012-25-05

[Federal Register Volume 77, Number 248 (Thursday, December 27, 2012)]
[Rules and Regulations]
[Pages 76230-76232]
From the Federal Register Online via the Government Publishing Office [<a href="http://www.gpo.gov">www.gpo.gov</a>]
[FR Doc No: 2012-29999]


-----------------------------------------------------------------------

DEPARTMENT OF TRANSPORTATION

Federal Aviation Administration

14 CFR Part 39

[Docket No. FAA-2011-1222; Directorate Identifier 2010-NM-268-AD;
Amendment 39-17286; AD 2012-25-05]
RIN 2120-AA64


Airworthiness Directives; The Boeing Company Airplanes

AGENCY: Federal Aviation Administration (FAA), DOT.

ACTION: Final rule.

-----------------------------------------------------------------------

SUMMARY: We are adopting a new airworthiness directive (AD) for certain
The Boeing Company Model 737-600, -700, -700C, -800, -900, and -900ER
series airplanes. This AD was prompted by reports of escape slides
failing to deploy from the forward and aft right-hand doors during
scheduled maintenance slide deployments. This AD requires modifying the
escape slide. Also, for certain airplanes, this AD requires modifying
or replacing the Vespel piston. For certain other airplanes, this AD
requires an additional modification of the escape slide. We are issuing
this AD to prevent failure of an escape slide to deploy, which could
result in the slide being unusable during an emergency evacuation and
increased likelihood of injury to passengers or crewmembers due to the
difficulty in evacuating the airplane.

DATES: This AD is effective January 31, 2013.
    The Director of the Federal Register approved the incorporation by
reference of certain publications listed in the AD as of January 31,
2013.

ADDRESSES: For service information identified in this AD, Goodrich
Corporation, Aircraft Interior Products ATTN: Technical Publications,
3414 South Fifth Street, Phoenix, Arizona 85040; phone: 602-243-2270;
Internet: <a href="http://www.goodrich.com/TechPubs">http://www.goodrich.com/TechPubs</a>. You may review copies of
the referenced service information at the FAA, Transport Airplane
Directorate, 1601 Lind Avenue SW., Renton, WA. For information on the
availability of this material at the FAA, call 425-227-1221.

Examining the AD Docket

    You may examine the AD docket on the Internet at <a href="http://www.regulations.gov">http://www.regulations.gov</a>; or in person at the Docket Management Facility
between 9 a.m. and 5 p.m., Monday through Friday, except Federal
holidays. The AD docket contains this AD, the regulatory evaluation,
any comments received, and other information. The address for the
Docket Office (phone: 800-647-5527) is Document Management Facility,
U.S. Department of Transportation, Docket Operations, M-30, West
Building Ground Floor, Room W12-140, 1200 New Jersey Avenue SE.,
Washington, DC 20590.

FOR FURTHER INFORMATION CONTACT: Sarah Piccola, Aerospace Engineer,
Cabin Safety & Environmental Systems Branch, ANM-150S, Seattle Aircraft
Certification Office (ACO), FAA, 1601 Lind Avenue SW., Renton, WA
98057-3356; phone: 425-917-6483; fax: 425-917-6590; email:
<a href="/cdn-cgi/l/email-protection#bbc8dac9dad395cbd2d8d8d4d7dafbdddada95dcd4cd"><span class="__cf_email__" data-cfemail="d2a1b3a0b3bafca2bbb1b1bdbeb392b4b3b3fcb5bda4">[email&#160;protected]</span></a>.

SUPPLEMENTARY INFORMATION:

Discussion

    We issued a supplemental notice of proposed rulemaking (SNPRM) to
amend 14 CFR part 39 to include an airworthiness directive (AD) that
would apply to the specified products. That SNPRM published in the
Federal Register on August 31, 2012 (77 FR 53155). The original NPRM
(76 FR 69159, November 8, 2011) proposed to require checking the escape
slide girt for serviceability, and replacement if necessary; modifying
the cable routing provision; replacing the regulator padding; modifying
the aspirator orientation; and modifying the valise. The original NPRM
also proposed to require, for certain airplanes, modifying or replacing
the Vespel piston, modifying the pilot valve regulator, installing a
new firing cable and safety pin, and modifying the slide valise. The
SNPRM proposed to add airplanes to the applicability of the original
NPRM, and specify revised service information. For certain other
airplanes, this AD requires an additional modification of the escape
slide.

Comments

    We gave the public the opportunity to participate in developing
this AD. We have considered the comments received.

Support for the SNPRM (77 FR 53155, August 31, 2012)

    Boeing stated that it concurs with the contents of the SNPRM (77 FR
53155, August 31, 2012), and therefore, no additional comments will be
forthcoming.
    Goodrich Corporation stated that the comments it submitted to the
original NPRM (76 FR 69159, November 8, 2011) have been satisfactorily
addressed, and therefore, it has no additional comments or changes to
offer.

Conclusion

    We reviewed the relevant data, considered the comments received,
and determined that air safety and the public interest require adopting
the AD as proposed-except for minor editorial changes. We have
determined that these minor changes:
    <bullet> Are consistent with the intent that was proposed in the
SNPRM (77 FR 53155, August 31, 2012) for correcting the unsafe
condition; and
    <bullet> Do not add any additional burden upon the public than was
already proposed in the SNPRM (77 FR 53155, August 31, 2012).

Additional Change Made to This Final Rule

    We have removed the girt replacement on-condition cost specified in
the SNPRM (77 FR 53155, August 31, 2012) from this AD, because the
proposed girt check for continued serviceability was removed from the
SNPRM and is not included in this AD.

Costs of Compliance

    We estimate that this AD affects 557 airplanes of U.S. registry.
    We estimate the following costs to comply with this AD:

[[Page 76231]]



                                                 Estimated Costs
----------------------------------------------------------------------------------------------------------------
                                                                                                 Cost on U.S.
             Action                   Labor cost          Parts cost       Cost per product        operators
----------------------------------------------------------------------------------------------------------------
Modify girt and valise, and       2 work-hours x $85  $223..............  $393..............  $218,901.
 replace padding.                  per hour = $170.
Modify regulator valve, install   1 work-hour x $85   Between $1,749 and  Between $1,834 and  Between $1,021,538
 cable and pin, and modify slide   per hour = $85.     $1,836.             $1,921.             and $1,069,997.
 valise.
Modify Vespel piston............  1 work-hour x $85   $0................  $85...............  $47,345.
                                   per hour = $85.
Optional Vespel piston            Up to 1 work-hour   Up to $612........  Up to $697........  Up to $388,229.
 replacement.                      x $85 per hour =
                                   $85.
----------------------------------------------------------------------------------------------------------------

    According to the parts supplier, some of the costs of this AD may
be covered under warranty, thereby reducing the cost impact on affected
individuals. We do not control warranty coverage for affected
individuals. As a result, we have included all costs in our cost
estimate.

Authority for This Rulemaking

    Title 49 of the United States Code specifies the FAA's authority to
issue rules on aviation safety. Subtitle I, section 106, describes the
authority of the FAA Administrator. Subtitle VII: Aviation Programs,
describes in more detail the scope of the Agency's authority.
    We are issuing this rulemaking under the authority described in
Subtitle VII, Part A, Subpart III, Section 44701: ``General
requirements.'' Under that section, Congress charges the FAA with
promoting safe flight of civil aircraft in air commerce by prescribing
regulations for practices, methods, and procedures the Administrator
finds necessary for safety in air commerce. This regulation is within
the scope of that authority because it addresses an unsafe condition
that is likely to exist or develop on products identified in this
rulemaking action.

Regulatory Findings

    This AD will not have federalism implications under Executive Order
13132. This AD will not have a substantial direct effect on the States,
on the relationship between the national government and the States, or
on the distribution of power and responsibilities among the various
levels of government.
    For the reasons discussed above, I certify that this AD:
    (1) Is not a ``significant regulatory action'' under Executive
Order 12866,
    (2) Is not a ``significant rule'' under DOT Regulatory Policies and
Procedures (44 FR 11034, February 26, 1979),
    (3) Will not affect intrastate aviation in Alaska, and
    (4) Will not have a significant economic impact, positive or
negative, on a substantial number of small entities under the criteria
of the Regulatory Flexibility Act.

List of Subjects in 14 CFR Part 39

    Air transportation, Aircraft, Aviation safety, Incorporation by
reference, Safety.

Adoption of the Amendment

    Accordingly, under the authority delegated to me by the
Administrator, the FAA amends 14 CFR part 39 as follows:

PART 39--AIRWORTHINESS DIRECTIVES

0
1. The authority citation for part 39 continues to read as follows:

    Authority: 49 U.S.C. 106(g), 40113, 44701.


Sec.  39.13  [Amended]

0
2. The FAA amends Sec.  39.13 by adding the following new airworthiness
directive (AD):

2012-25-05 The Boeing Company: Amendment 39-17286; Docket No. FAA-
2011-1222; Directorate Identifier 2010-NM-268-AD.

(a) Effective Date

    This AD is effective January 31, 2013.

(b) Affected ADs

    This AD affects AD 2008-24-08, Amendment 39-15748 (73 FR 72320,
November 28, 2008).

(c) Applicability

    This AD applies to The Boeing Company Model 737-600, -700, -
700C, -800, -900, and -900ER series airplanes, certificated in any
category, with Goodrich Corporation door escape slide part number
(P/N) 5A3307-1, -3, -5, or -301, serial numbers (S/N) BNG0001
through BNG14499 inclusive.

(d) Subject

    Joint Aircraft System Component (JASC)/Air Transport Association
(ATA) of America Code 25, Equipment/Furnishings.

(e) Unsafe Condition

    This AD was prompted by reports of escape slides failing to
deploy from the forward and aft right-hand doors during scheduled
maintenance slide deployments. We are issuing this AD to prevent
failure of an escape slide to deploy, which could result in the
slide being unusable during an emergency evacuation and increased
likelihood of injury to passengers or crewmembers due to the
difficulty in evacuating the airplane.

(f) Compliance

    Comply with this AD within the compliance times specified,
unless already done.

(g) Slide Modification

    Within 36 months after the effective date of this AD: Modify the
escape slide, in accordance with the Accomplishment Instructions of
Goodrich Service Bulletin 5A3307-25-389, Revision 2, dated May 4,
2012.

(h) Concurrent Requirements

    (1) For slide P/N 5A3307-301: Prior to or concurrently with
accomplishing the actions required by paragraph (g) of this AD,
modify the escape slide, in accordance with the Accomplishment
Instructions of Goodrich Service Bulletin 5A3307-25-339, Revision 5,
dated May 4, 2012.
    (2) For slide P/N 5A3307-301 or 5A3307-5: Prior to or
concurrently with accomplishing the actions required by paragraph
(g) of this AD, modify the Vespel piston in the regulator valves, or
replace the Vespel piston with a new or serviceable Vespel piston P/
N 3A3566-2 or 3A3832-2, as applicable, in accordance with the
Accomplishment Instructions of Goodrich Service Bulletin 25-349,
Revision 1, dated January 11, 2010.

(i) Credit for Previous Actions

    (1) This paragraph provides credit for the actions required by
paragraph (h)(1) of this AD, if those actions were performed before
the effective date of this AD using the service bulletins specified
in paragraphs (i)(1)(i) through (i)(1)(iv) of this AD, which are not
incorporated by reference in this AD.
    (i) Goodrich Service Bulletin 5A3307-25-339, Revision 1, dated
September 26, 2003.
    (ii) Goodrich Service Bulletin 5A3307-25-339, Revision 2, dated
March 31, 2004.
    (iii) Goodrich Service Bulletin 5A3307-25-339, Revision 3, dated
May 8, 2009.
    (iv) Goodrich Service Bulletin 5A3307-25-339, Revision 4, dated
October 1, 2011.
    (2) This paragraph provides credit for the modification or
replacement of the Vespel piston in the regulator valves required by
paragraph (h)(2) of this AD, if those actions

[[Page 76232]]

were performed before the effective date of this AD using Goodrich
Service Bulletin 25-349, dated September 15, 2004, which is not
incorporated by reference in this AD.

(j) Alternative Methods of Compliance (AMOCs)

    (1) The Manager, Seattle Aircraft Certification Office (ACO),
FAA, has the authority to approve AMOCs for this AD, if requested
using the procedures found in 14 CFR 39.19. In accordance with 14
CFR 39.19, send your request to your principal inspector or local
Flight Standards District Office, as appropriate. If sending
information directly to the manager of the ACO, send it to the
attention of the person identified in the Related Information
section of this AD. Information may be emailed to: <a href="/cdn-cgi/l/email-protection#251c08646b6808764044515149400864666a0864686a66087740545040565156654344440b424a53"><span class="__cf_email__" data-cfemail="f4cdd9b5bab9d9a7919580809891d9b5b7bbd9b5b9bbb7d9a691858191878087b4929595da939b82">[email&#160;protected]</span></a>.
    (2) Before using any approved AMOC, notify your appropriate
principal inspector, or lacking a principal inspector, the manager
of the local flight standards district office/certificate holding
district office.

 (k) Related Information

    (1) For more information about this AD, contact Sarah Piccola,
Aerospace Engineer, Cabin Safety & Environmental Systems Branch,
ANM-150S, Seattle Aircraft Certification Office (ACO), FAA, 1601
Lind Avenue SW., Renton, WA 98057-3356; phone: 425-917-6483; fax:
425-917-6590; email: <a href="/cdn-cgi/l/email-protection#f4879586959cda849d97979b9895b4929595da939b82"><span class="__cf_email__" data-cfemail="780b190a19105608111b1b171419381e1919561f170e">[email&#160;protected]</span></a>.
    (2) For Goodrich service information identified in this AD,
contact Goodrich Corporation, Aircraft Interior Products, ATTN:
Technical Publications, 3414 South Fifth Street, Phoenix, Arizona
85040; phone: 602-243-2270; Internet: <a href="http://www.goodrich.com/TechPubs">http://www.goodrich.com/TechPubs</a>.

(l) Material Incorporated by Reference

    (1) The Director of the Federal Register approved the
incorporation by reference (IBR) of the service information listed
in this paragraph under 5 U.S.C. 552(a) and 1 CFR part 51.
    (2) You must use this service information as applicable to do
the actions required by this AD, unless the AD specifies otherwise.
    (i) Goodrich Service Bulletin 25-349, Revision 1, dated January
11, 2010.
    (ii) Goodrich Service Bulletin 5A3307-25-339, Revision 5, dated
May 4, 2012.
    (iii) Goodrich Service Bulletin 5A3307-25-389, Revision 2, dated
May 4, 2012.
    (3) For Goodrich service information identified in this AD,
contact Goodrich Corporation, Aircraft Interior Products, ATTN:
Technical Publications, 3414 South Fifth Street, Phoenix, Arizona
85040; phone: 602-243-2270; Internet: <a href="http://www.goodrich.com/TechPubs">http://www.goodrich.com/TechPubs</a>.
    (4) You may review copies of the referenced service information
at the FAA, Transport Airplane Directorate, 1601 Lind Avenue SW.,
Renton, WA. For information on the availability of this material at
the FAA, call 425-227-1221.
    (5) You may view this service information that is incorporated
by reference at the National Archives and Records Administration
(NARA). For information on the availability of this material at
NARA, call 202-741-6030, or go to: <a href="http://www.archives.gov/federal-register/cfr/ibr-locations.html">http://www.archives.gov/federal-register/cfr/ibr-locations.html</a>.

    Issued in Renton, Washington, on December 4, 2012.
Kalene C. Yanamura,
Acting Manager, Transport Airplane Directorate, Aircraft Certification
Service.
[FR Doc. 2012-29999 Filed 12-24-12; 8:45 am]
BILLING CODE 4910-13-P
